Functions and features:
1. Double cutter and double axis cutting, double axis alternating between four axes.
2. Imported ball screw and linear bearing are adopted.
3. Automatic adjustment of cutting angle.
4. Round knife cutting, automatic cooling and lubrication.
5. Servo feed, servo motor control cutting width.
6. It can be equipped with knife following device to protect the shaft when cutting small shaft
7. The distance between two shafts can be customized according to customers, such as 250mm shaft distance
8. The lubrication mode of timing and quantitative automatic oil injection is adopted to improve the service life of screw rod and slide rail

Main technical parameters

Machine specifications	1300mm 1600mm
Effective width	130mm 160mm
Slitting accuracy	±0.05mm
Maximum cutting diameter	140mm (select 76.2mm shaft). If the machine with 250mm shaft spacing is selected, 180mm can be cut
Inner diameter of slitting paper core	25.4mm-76.2mm
Maximum tool diameter	450mm
Equipment power	8kw
Supply voltage	380V 50HZ 3Ф
Working pressure	0.4-0.6MPa
Dimensions	2900*1750*1400mm（1300, 1600 plus 300 mm）
